P242F/009263 – Diesel Particulate Filter (Bank 1): Restricted/Clogged

Possible Symptoms

  • Malfunction Indicator Light (MIL) ON

Possible Causes

  • Diesel Particle Filter (DPF) restricted/clogged
  • Diesel Particle Filter (DPF) faulty

Possible Solutions

  • Check Engine related Fault Codes / Problems
  • Check Diesel Particle Filter (DPF) Load
  • Perform Diesel Particle Filter (DPF) Service Regeneration

Special Notes

  • When found in VW Crafter (2E): 2.5l CR-TDI Engine (BJJ, BJK, BJL, BJM):
    • Depending on the Model Year and/or if the Diesel Particle Filter (DPF) has been replaced already, different Generations of the Filter may be installed. If in doubt, check the Filter Part Number. Generation 2 (DPF2) were 2E0-254-700-E and 2E0-254-700-F, while Generation 3 (DPF3) were 2E0-254-700-G/GX.
    • Check Engine Control Module (ECM) Software Level and installed Diesel Particle Filter (DPF) Part Number/Generation. Information on the latest Software Versions can be found in TPI 2020740 (DPF2) and TPI 2020722 (DPF3).
    • When Replacing a DPF2 with DPF3, the Engine Control Module (ECM) Software Version must be updated as well. Operating a DPF2 with DPF3 Software or vice versa will damage the DPF. For Details see TPI 2015609.
    • If the Vehicle is used mainly for Short Trip/Distance Driving (for Example as a Delivery Truck), consider applying the special Short Trip/Distance Software as described in TPI 2018140.
